Advent Communications
209298 - DVE5000 Technical Operation Handbook - CL140042 Page 60 of 110
7.2.5 ELAPSED HOURS
By using the up / down arrow keys, highlight ELAPSED HOURS and press ENTER key.
This screen will be displayed: -
HPA B HV Hours:
- Elapsed Hours -
HPA A HV Hours:
HPA A (B) HV Hours: This menu option shows the number of hours the High Voltage has been
applied to the TWTA.
Menu is ‘read only’.
Note this is not applicable to SSPA’s.
PRESS ESCAPE to return up a menu level.
7.2.6 HELIX
By using the up / down arrow keys, highlight HELIX and press ENTER key.
This screen will be displayed: -
- Helix -
HPA A Helix I:
HPA B Helix I:
HPA A (B) Helix I: This menu shows the Helix current in each amplifier. Menu is ‘read only’.
To Next Page
