209298 - DVE5000 Technical Operation Handbook - CL140042 Page 35 of 110
PRESS ESCAPE to return up a menu level.
6.1.3 ENCODER SETUP
By using the up / down arrow keys, highlight ENCODER SETUP and press ENTER key.
This screen will be displayed: -
IDENTIFIERS:
- prompt -
PROFILE:
SCRAMBLING:
VBI/DATA:
6.1.4 PROFILE
By using the up / down arrow keys, highlight PROFILE and press ENTER key.
This screen will be displayed: -
- Encoder -
Video Mb/s:
Profile:
Auto Video Rate:
Delay:
Video Mb/s: Set the required video data rate, unless in ‘auto video rate’ which overrides this
value based on the symbol rate; Use up / down arrow keys to select, press ENTER to confirm or
ESCAPE to cancel selection.
Profile: Choices are 4.2.0 and 4.2.2 (option at SD); Use up / down arrow keys to select, press
ENTER to confirm or ESCAPE to cancel selection.
Auto Video Rate: When ON, automatically adjusts the video data rate to fill the amount of
bandwidth available defined by the symbol rate, less audio, data and multiplexer overhead.
Delay: choices are standard or low in SD only.
PRESS ESCAPE to return up a menu level.
