Advent DVE5000 SERIES User Manual

Advent Communications
209298 - DVE5000 Technical Operation Handbook - CL140042 Page 22 of 110
HPA CONTROL:
Serial control of a variety of HPA’s or SSPA’s can be controlled by connection to this
15 Way D Female, RS485 port as shown below.
15W
PIN# Signal Description Remark
8 HPA RX -
RS485 RX data - (B) FROM HPA
to DVE Twisted pair with RX+
9 HPA RX +
RS485 RX data+ (A) FROM HPA
to DVE Twisted pair with RX-
10 HPA TX-
RS485 TX data - (B) TO HPA from
DVE Twisted pair with TX+
11 HPA TX+
RS485 TX data + (A) TO HPA
from DVE Twisted pair with TX-
12 GND Ground connection Overall Screen
STATUS RELAY:
A pair of ground free relay contacts are provide to give a “summary alarm” status of the
DVE5000. Normally this is configured at the factory for an “open circuit” indicating a fail.
This configuration may be reversed by the use of internal ‘status’ link on the control PCB.
If the DVE5000 looses power or has a “major” alarm as listed in Chapter 3.4 the relay contacts
will open.
15W PIN# Signal Description Remark
14 Status relay Relay contact opens on fault
Internal link to swap
NC/NO
15 Status relay Relay contact opens on fault
Internal link to swap
NC/NO
