AEQ XPEAK
IP Intercom System
12
1.5. Xpeak_IF I/O Interface Description.
Ergonomics:
• 4 Channel audio I/O converter for analog, USB and AoIP Dante / AES67 to 4
bidirectional G722 encoded channels that integrates with the virtual matrix or the Party-
Line system.
• USB connection: The 4 USB audio ports are type B and allow you to connect audio
from a PC.
• Ethernet connection: Internal switch with two external network ports. Different uses:
daisy chain, separation between Dante audio and encoded audio + Control.
• GPIOs: Mini-Hartmann connectors include 4 opto-coupled GPIs and 4 GPOs, external
power pin and ground.
• 1.54" color TFT screen: Allows information such as IP address, audio presence and
status to be displayed.
• Encoder and menu key to navigate the user interface and facilitate configuration and
status viewing.
Dimensions and weight:
• Front: Width: 482.6 mm. Height: 44.5 mm.
• Depth: 155 mm.
• Weight: 2.42 Kg.
1.6. Xpeak Virtual application description.
• Virtual user panel.
• PC software.
• Windows operating system.
• 16 virtual crossover keys.
• Compatible with Xpeak in all work
modes.
• Adaptive screen configuration:
vertical, horizontal or square.
