AERMEC Turbocor User Manual

18
Alarms List
Code Description Reset
AL001 From digital input Auto
AL002 Phase or voltage monitor rearm
AL003 Evaporator Anti-freeze rearm
AL004 Compressor 1 circuit breaker rearm
AL005 System Flow Meter rearm
AL006 From digital input, EEV Auto
AL007 Pressure Switch high pressure rearm
AL008 Transducer High pressure rearm
AL009 Pressure Switch low pressure rearm
AL010 Transducer low pressure rearm
AL011 Critical low pressure rearm
AL012 Fan/condenser pump circuit breaker rearm
AL013 System pump 1 circuit breaker rearm
AL014 System pump 2 circuit breaker rearm
AL015 System pump 1 maintenance Auto
AL016 System pump 2 maintenance Auto
AL017 Compressor 1 Maintenance Auto
AL018 Compressor 2 Maintenance Auto
AL019 U1 probe faulty or disconnected Auto
AL020 U2 probe faulty or disconnected Auto
AL021 U3 probe faulty or disconnected Auto
AL022 U4 probe faulty or disconnected Auto
AL023 U5 probe faulty or disconnected Auto
AL024 U6 probe faulty or disconnected Auto
AL025 U7 probe faulty or disconnected Auto
AL026 U8 probe faulty or disconnected Auto
AL027 U9 probe faulty or disconnected Auto
AL028 U10 probe faulty or disconnected Auto
AL029 Turbocor1 Pressing line Gas High Temp. Man
AL030 Turbocor2 Pressing line Gas High Temp. Man
AL031 Turbocor1 Inverter temp Auto
AL032 Turbocor1 Discharge temp Auto
AL033 Turbocor1 Suction pres Auto
AL034 Turbocor1 Discharge pres Auto
AL035 Turbocor1 Rotor Lock Auto
AL036 Turbocor1 Phase current
Man. Remove
voltage for 30s
AL037 Turbocor1 Cavity temp TurboAL
AL038 Turbocor1 overcurrent TurboAL
AL039 Turbocor1 Compressor ratio TurboAL
AL040 Turbocor1 DC Low Voltage TurboAL
AL041 Turbocor 1 SCR temp TurboAL
AL042 Turbocor1 System Locked out
Man. Remove
voltage for 30s
AL043 Turbocor1 Calibration failed TurboAL
AL044 Turbocor1 Startup failed TurboAL
AL045 Turbocor1 Axial displacement TurboAL
AL046 Turbocor1 Axial static load TurboAL
AL047 Turbocor1 Front radial disp X TurboAL
AL048 Turbocor1 Front radial disp Y TurboAL
AL049 Turbocor1 Front radial load X TurboAL
AL050 Turbocor1 Front radial load Y TurboAL
AL051 Turbocor1 Back radial disp X TurboAL
AL052 Turbocor1 Back radial disp Y TurboAL
AL053 Turbocor1 Back radial load X TurboAL
AL054 Turbocor1 Back radial load Y TurboAL
AL055 Turbocor1 Sigle phase Overcurrent TurboAL
AL056 Turbocor1 DC high voltage TurboAL
AL057 Turbocor1 High current TurboAL
AL058 Turbocor1 Sensors error TurboAL
AL059 Turbocor1 IGBT error TurboAL
AL060 Turbocor1 High widing temp TurboAL
Code Description Reset
AL061 Turbocor1 Bearing error TurboAL
AL062 Turbocor1 Superheat TurboAL
AL063 Turbocor1 Inverter error signal TurboAL
AL064 Turbocor1 AVC data missing TurboAL
AL065 Turbocor1 Motor Back EMF low TurboAL
AL066 Turbocor1 EEprom error TurboAL
AL067 Turbocor1 Generator mode TurboAL
AL068 Turbocor1 SCR phase TurboAL
AL069 Turbocor1 oine Auto
AL070 Turbocor1 Startup failed TurboAL
AL071 Turbocor2 Inverter temp TurboAL
AL072 Turbocor2 Discharge temp TurboAL
AL073 Turbocor2 Suction pres TurboAL
AL074 Turbocor2 Discharge pres TurboAL
AL075 Turbocor2 Rotor Lock Auto
AL076 Turbocor2 Phase current
Man. Remove
voltage for 30s
AL077 Turbocor2 Cavity temp TurboAL
AL078 Turbocor2 overcurrent TurboAL
AL079 Turbocor2 Compressor ratio TurboAL
AL080 Turbocor2 DC Low Voltage TurboAL
AL081 Turbocor 2 SCR temp TurboAL
AL082 Turbocor2 System Locked out
Man. Remove
voltage for 30s
AL083 Turbocor2 Calibration failed TurboAL
AL084 Turbocor2 Startup failed TurboAL
AL085 Turbocor2 Axial displacement TurboAL
AL086 Turbocor2 Axial static load TurboAL
AL087 Turbocor2 Front radial disp X TurboAL
AL088 Turbocor2 Front radial disp Y TurboAL
AL089 Turbocor2 Front radial load X TurboAL
AL090 Turbocor2 Front radial load Y TurboAL
AL091 Turbocor2 Back radial disp X TurboAL
AL092 Turbocor2 Back radial disp Y TurboAL
AL093 Turbocor2 Back radial load X TurboAL
AL094 Turbocor2 Back radial load Y TurboAL
AL095 Turbocor2 Sigle phase Overcurrent TurboAL
AL096 Turbocor2 DC High Voltage TurboAL
AL097 Turbocor2 High current TurboAL
AL098 Turbocor2 Sensors error TurboAL
AL099 Turbocor2 IGBT error TurboAL
AL100 Turbocor2 High widing temp TurboAL
AL101 Turbocor2 Bearing error TurboAL
AL102 Turbocor2 Superheat TurboAL
AL103 Turbocor2 Inverter error signal TurboAL
AL104 Turbocor2 AVC data missing TurboAL
AL105 Turbocor2 Motor Back EMF low TurboAL
AL106 Turbocor2 EEprom error TurboAL
AL107 Turbocor2 Generator mode TurboAL
AL108 Turbocor2 SCR phase TurboAL
AL109 Turbocor2 oine Auto
AL110 Turbocor2 Startup failed TurboAL
AL111 EVD Oine Auto
AL112 EVD S1 Probe Error Auto
AL113 EVD S2 Probe Error Auto
AL114 EVD EEV motor error Auto
AL115 EVD EEprom damaged Man
AL116 Low Liquid Level Auto
AL117 High Liquid Level Auto
AL118
Modbus master disconnected
(communication with Turbocor)
Auto
AL119 Compressor 2 circuit breaker Man
Each alarm can have a specic type of reset, these types can be:
Auto (automac) = the alarm disappears when the event which generated it ceases;
Man (manual) = to resume normal operaon, manual recognion by an operator is required (via a touch screen or BMS);
Semi (semi-automac) = the alarm is automac, but if it is triggered more than 3 mes in an hour then it becomes with manual reset
TurboAL = characterisc alarm of Turbocor compressors. It is automacally reset with the following procedure:
1. Turn o the aected compressor removing request;
2. Wait for a me of 30s (seable);
3. 10% power is given to the TurboCor;
4. The Turbocor resets the alarm;
5. The TurboCor reposions the IGV valve (approximately 120 s);
6. the pCO can turn on the TurboCor compressor again;
