INPUTS/OUTPUTS MENU
These pages contain the values and states associated with inputs and
outputs available on the unit
Inputs/outputs menu - TBX digital inputs page
Inputs/outputs menu - WTX/WTG digital inputs page
Index Meaning
1
The values read by the transducers and by the probes connected to the various analogue inputs
available on the unit board are indicated
2
Index Meaning
1
The values read by the transducers and by the probes connected to the various analogue inputs
available on the unit board are indicated
2
ATTENTION: some pages (or items within the same pages) of
this menu may not be visible as they are specic for certain
models or types of unit (depending on the conguraon,
some components may not be available), however, this
manual will list all possible pages. For further informaon
on the components present in the unit, refer to the technical
manual.
ACTIONS
AVAILABLE:
ACTIONS
AVAILABLE:
A
Open the menu selecting page
B
Open the alarm menu
C
Go to next page
A
Open the menu selecting page
B
Open the alarm menu
C
Go to next page
