14
GB
6795773_01
VMF system - Implement zone
B
The fi gure to the left indicates which rooms make up zone B; the master unit
installed in this zone is identifi ed on VMF-E5 by the label “NIGHT B”.
In this case, the zone is served by one unit alone, and it is therefore managed
as master. The type of unit chosen obliges the installer to use the VMF-E1
thermostat.
Omnia HL (1)
VMF-E1 (2)
VMF-E4 (3)
Material for ZONE
B
An OMNIA HL unit has been selected in this zone to meet requests; the fan coil will
be piloted by installation of a wall-mounted VMF-E4 panel.
The material required to implement this zone is:
