Complete VMF system
The fi gure below describes the air-conditioning system used as a reference in this manual. This section describes
in detail the hydraulic connections between the fan coils and the collector in the technical room.
ATTENTION: the fi gure only indicates the hydraulic connections of all the indoor units.
Unit (3)
(Zone master
C
)
“Bathroom”
Unit (2)
(Zone master
B
)
“Night B”
Unit (4)
(Zone master
D
)
“Kitchen”
Unit (5)
(Zone slave
D
)
Unit (8)
(2
nd
zone slave
E
)
Unit (6)
(Zone master
E
)
"Day"
Unit (7)
(1
st
zone slave
E
)
Unit (1)
(Zone master
A
)
“Night A”
