Connection Reference chapters for implementation of the connections
1
VMF-ACS power supply.
2
Connect the supplementary electric resistance.
3
RS485 serial connection.
4
VMF-E5 serial connection.
5
DHW probe connection.
6
Connection V3V (1) or DHW pump.
7
Boiler or V3V (3) or system pump connection.
8
System storage tank probe connection.
9
Multifunction output or V3V (2) connection.
MULTI-VALVE system:
1
VMF-ACS
Heat Pump
ACS
Storage tank
system
VMF-E5
V3V (1)
V3V (2)
V3V (3)
2
3 456
7 89
To Next Page
