VMF system - Implement zone
C
The fi gure to the left indicates which rooms make up zone C; the master unit
installed in this zone is identifi ed on VMF-E5 by the label “Bathroom”.
In this case, the zone is served by one unit alone (master); the type of unit
chosen obliges the installer to use the VMF-E1 thermostat.
Omnia HL (1)
VMF-E1 (2)
VMF-E2H (3)
Material for ZONE
C
An OMNIA HL unit has been selected in this zone to meet requests; the unit will be
piloted by installation of a VMF-E2H control interface.
The material required to implement this zone is:
