Chapter 6: Replacing Assemblies
To remove and replace the keyboard and flat-panel display assemblies
6–21
9
To reas
semble the front panel assembly, reverse the above procedure.
The cursor keyboard has holes that fit over locating pins in the front panel casting.
Be sure to torque the hex nuts for the BNC connectors and the T15 torx screws to 2 Nm (18 in-lb).
CAUTION PREVENT GLASS BREAKAGE!
Use care when handling the Lens Glass and the FPD monitor to prevent glass breakage.
Inspect the inside surfaces of the Lens Glass and the Display Monitor closely for dust, smudges,
and finger prints. Viewing these with line-of-sight 45 degrees to the surface is the best method
for seeing subtle flaws. Clean the inside surfaces with glass cleaner and lint-free lens paper before
re-assembly. Clean the front of the FPD monitor by applying the glass cleaner to the lint-free
lens paper or soft lens cloth. Do not apply glass cleaner directly to the FPD monitor.
