2 Installing GC Columns
See Figure 4.
4 Feed the outlet side of the column through the 1 o’clock positioned clip so
that the column outlet is pointing toward the front of the column cage. See
Figure 5.
Figure 4 Column with column clips attached
Column clip
(1 o’clock postion)
Column clips
(3 o’clock position)
Column outlet
CAUTION
Be careful not to scratch the column coating.
