Replacement Parts 9
Troubleshooting and Maintenance Manual 197
EI source
Table 1 8 Analyzer screws
Description Part number
Heater/Sensor (quad) setscrew 0515-1446
Ion source thumbscrew G1099-20138
Magnet mounting screws 0515-1046
Screw – magnet bracket to source radiator 0515-1602
Screws – source radiator and detector to quad radiator G3170-20123
Screws – mass filter contact assembly/heater block G3170-20122
Screws – radiator. Mounting brackets quadrupole
board
0515-0430
Source radiator screws 0515-1052
Screws for Quad Stop 0515-0221
Table 1 9 Inert EI ion source
Description Part number
Inert ion source, new G7000-65700
Inert ion source, rebuilt G7000-69700
11 Drawout cyclinder G1999-20444
12 Drawout plate – 3 mm Inert G2589-20100
Drawout plate – 6 mm Inert G2589-20045
9 Entrance lens G3170-20126
3 EI filament G2590-80070
EI high temp filament G2590-60053
4 Interface socket G7000-20136
10 Ion focus lens G1999-20443
