30 708-DS / 709-DS Operator’s Manual
3 Setting Up the 708-DS / 709-DS
EVT Probe Installation (708-DS)
1 If applicable, insert the EVT Probe cable into the VESSEL TEMP
jack on the rear of the dissolution apparatus drive unit.
2 Place the vessel temperature probe in the hole in the vessel plate, at
the left side rear of the apparatus.
Power Cord Connections
1 Connect or verify connections of power cords to all components.
2 Plug the cords into electrical outlets of the appropriate voltage.
708-DS / 709-DS Initial Power Up
1 Turn on the power of the dissolution apparatus using the switch
located on the left side of the drive unit.
2 Ensure the self test conducted upon initialization passes, which is
indicated by a green check mark.
Ensure the correct voltage has been supplied prior to connecting the
power cables.
Ensure the retaining ties have been removed. Failure to do so could
result in significant damage to the instrument.
