From the Diagnostics screen:
• Press Next to proceed to the second Diagnostics screen.
• Press Finish to return to the Menu screen.
Manifold Control The manifold may be ejected for cleaning and maintenance. Before
ejecting, raise the head, disconnect the two thermistor cables, remove
the tubing from the tubing clamps, and remove the evaporation covers.
Press Eject to lower the manifold until it is free. To reattach the
manifold, insert it into the guides and gently lift it up while pressing
Load. Release the manifold once it begins to rise on its own. Press Stop
to stop all manifold motion.
Dosage Delivery
Module Control
The DDMs are solenoid activated doors that hold a tablet above each
vessel. Press the corresponding button to open a DDM. Press All to
open all DDMs simultaneously.
Drive Press Drive to raise the drive unit. Keep pressing it to raise the drive
unit to the maximum height. Release the button to stop the motion. Press
Drive to lower the drive unit.
Manifold Press Manifold to raise the manifold to the maximum height. Press
Manifold to lower the manifold to the appropriate position based on
the apparatus type and volume.
Table 1 0 Menu Screen - Diagnostics Screen 1
Option Function
To Next Page
