NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
AM On/Off 10 dB/V
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Waveform Menu
Displays the waveforms for internal amplitude
mo dulation.
Programming Codes
SCPI:
NONE, see the individual softkeys listed.
Analyzer:
NONE
See Also
4
MOD
5
, also see \AM" and \Mo dulation".
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
AM On/Off 10 dB/V
Function Group
MOD (MODULATION)
Menu Map
4
Description
This softkey activates the exponentially-scaled amplitude mo dulation
function. Amplitude mo dulation lets the RF output of the sw
ept
signal generator b e continuously and exp onentially varied at a rate
determined by the AM input. See \Specications" for the AM
characteristics, input range, and damage level. An asterisk next to
the key label indicates that this feature is active.
Programming Codes
SCPI:
AM:TYPE EXPponential
AM[:STATE] ON
j
OFF
j
1
j
0
Analyzer:
NONE
See Also
4
ALC
5
, CONNECTORS,
4
MOD
5
\Optimizing Swept Signal Generator Performance" in Chapter 1
Operating and Programming Reference A-15
