Step Dwell
be set on b oth the master and the slave. Since the master's sweep
time is typically determined by the measurement conguration, set
the slave to match the master.
For more accurate ramp sweeps, select
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Swp Span Cal Always
on
both the master and slaveswept signal generators. When this feature
is active it calibrates the frequency at the end of every frequency
band.
Programming Codes
SCPI:
SWEep:CONTrol:STATeON
j
OFF
j
1
j
0
SWEep:CONTrol:TYPE SLAVe
Analyzer:
NONE
See Also
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Step Control Master
,
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Step Swp Menu
aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa
Step Dwell
Function Group
FREQUENCY
Menu Map
2
Description
This softkey lets you set dwell times for points in the stepp ed
frequency mo de of sweep op eration. The dwell time for points in step
frequency sweep may range from 100

s to 3.2 s. The actual time
between points is the sum of dwell and phase lo ck times.
Select
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Step Dwell
, then use the entry area to enter the desired
value.
Programming Codes
SCPI:
SWEep[:FREQuency]:DWELl
<
num
>
[time sux] or
MAXimum
j
MINimum
Analyzer:
NONE
See Also
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Step Swp Menu
,
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Sweep Mode Step
Operating and Programming Reference S-67
