Programmer’s Guide 10-5
Menu Map with SCPI Commands
How to Enter Numbers and Characters
How to Enter Frequency Values
You enter frequency values the same way each time. First select a
numeric value (“100”) and then select a frequency unit (“MHz”).
*RPG knob does not allow unit entry.
Figure 10-2 Frequency—Enter the Value
Figure 10-3 Frequency—Enter the Unit
Enter the frequency using
the front panel keypad or
knob, or an attached keyboard.
Enter the unit by pressing the
softkey.
To Next Page
