Programmer’s Guide 6-23
Trace Data Transfers
Internal Measurement Arrays
Error Coefficient Arrays
The error coefficient arrays are either default values or are created
during a measurement calibration. These are used whenever correction
is on. They contain complex number pairs, are accessible via GPIB, and
are referenced as CH[1|2]SCORR1, CH[1|2]SCORR2, CH[1|2]SCORR3
and CH[1|2]SCORR4.
Table 6-5 Error Coefficient Arrays
NOTE These arrays do not apply to Broadband External measurements.
Selected Measurement Error Coefficient Arrays
Transmission (B/R) Response CH[1|2]SCORR1 Tracking
Transmission (B/R) Response & Isolation CH[1|2]SCORR1 Tracking
CH[1|2]SCORR2 Isolation Term
Transmission (B/R) Enhanced Response CH[1|2]SCORR1 Directivity
CH[1|2]SCORR2 Source Match
CH[1|2]SCORR3 Reflection Tracking
CH[1|2]SCORR4 Transmission Tracking
Reflection (A/R) CH[1|2]SCORR1 Directivity
CH[1|2]SCORR2 Source Match
CH[1|2]SCORR3 Tracking
Broadband Internal CH[1|2]SCORR1 R* Response
