1-8 Programmer’s Guide
Introduction to GPIB Programming
Interface Capabilities
Interface Capabilities
The analyzer has the following interface capabilities, defined by the
IEEE 488.1 standard:
Table 1-1 Analyzer Interface Capabilities (IEEE 488.1)
1. only when an HP Instrument BASIC program is running
2. only when an HP Instrument BASIC program is not running
SH1 full Source handshake capability
AH1 full Acceptor handshake capability
T6 basic Talker, Serial Poll, no Talk Only, unaddress if MLA
TE0 no Extended Talker capability
L4 basic Listener, no Listen Only, unaddress if MTA
LE0 no Extended Listener capability
SR1 full Service Request capability
RL1 full Remote/Local capability
DC1 full Device Clear capability
C1 System Controller capability
C2 send IFC and take charge Controller capability
C3 send REN Controller capability
C4
1
respond to SRQ
C8
1
send IFC, receive control, pass control, pass control to self
C12
2
send IF messages, receive control, pass control
E2 tri-state drivers
DT1 full device trigger capability
PP0 no parallel poll capability
