10-60 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-25 SCALE Functions, 8712ET/ES and 8714ET/ES
KEYSTROKES SCPI COMMAND
SCALE (hardkey entry)
Autoscale DISP:WIND[1|2]:TRAC:Y:AUTO ONCE
Scale/Div (enter value,
press Enter)
DISP:WIND[1|2]:TRAC:Y:PDIV <num>
Reference Level (enter value,
press Enter)
DISP:WIND1:TRAC:Y:RLEV <num>
Reference Position (enter value,
press Enter)
DISP:WIND1:TRAC:Y:RPOS <num>
Reference Tracking (menu selection only)
Off DISP:WIND[1|2]:TRAC:Y:TRACK [ON|OFF]
Track Peak DISP:WIND[1|2]:TRAC:Y:TRACK PEAK
Track Frequency DISP:WIND[1|2]:TRAC:Y:TRACK FREQ
Set Track Frequency (enter value
and unit press Enter)
DISP:WIND[1|2]:TRAC:Y:TRACK:FREQ <num>
Phase Offset (enter value,
press Enter)
SENS[1|2]:CORR:OFFS:PHAS <num> DEG
Electrical Delay (enter value and
unit, press Enter)
SENS[1|2]:CORR:EDEL:TIME <num> <unit>
