10-66 Programmer’s Guide
Menu Map with SCPI Commands
Menu Map for 8712ET/ES and 8714ET/ES
Table 10-27 SYSTEM OPTIONS Functions, 8712ET/ES and 8714ET/ES (5 of 9)
KEYSTROKES SCPI COMMAND
SYSTEM OPTIONS, Lan (continued)
Optional File Path
SYST:COMM:LAN:BOOT:TRAN:FILE:
NAME <STRING>
Parameters Received
(menu selection only)
SICL LAN Setup
(menu selection only)
Restore Defaults
(no SCPI command)
GPIB Name
SYST:COMM:LAN:SICL:GPIB:
NAME <STRING>
GPIB Log. Unit
SYST:COMM:LAN:SICL:GPIB:
LU #0~1024#
GPIB Dev Address
SYST:COMM:LAN:SICL:GPIB:
ADDR #0~20, \22~23#
SCPI Sock. Setup
(menu selection only)
Restore Defaults
(no SCPI command)
Socket Port No.
SYST:COMM:LAN:SCPI:SOCK:DATA:PORT:
NUM #0~4.74836e+07#
GPIB (menu selection only)
8712ES Address
(enter address,
press Enter)
SYST:COMM:GPIB:ADDR <address>
Talker Listener SYST:COMM:GPIB:CONT OFF
System Controller SYST:COMM:GPIB:CONT ON
GPIB Echo ON off SYST:COMM:GPIB:ECHO [ON|OFF]
8712ES Address
(enter address,
press Enter)
SYST:COMM:GPIB:ADDR <address>
