11-68 Programmer’s Guide
SCPI Command Summary
SCPI Device Command Summary
Table 11-25 TRACe (2 of 2)
1. The parameter type of the data is determined by the format selected — FORMat REAL uses
BLOCK data, FORMat ASCii uses NR3 data separated by commas.
2. See the example program titled “SIMCAL.” This program demonstrates how to create 2-port
correction arrays from measurements of the raw (uncorrected) calibration standards when
using the analyzer’s simcal command.
Example programs can be found in the following four locations:
• Example Programs Disk, 8712ET/ES and 8714ET/ES (DOS format): part number
08714-10003
• Example Programs Disk, 8712ET/ES and 8714ET/ES (LIF format):
part number 08714-10004
• Web site http://www.agilent.com. Use the search function to find Web pages related to
8712 example programs.
• Example Programs Guide, 8712ET/ES and 8714ET/ES:
part number 08714-90016
SUBSYSTEM COMMANDS FORM DESCRIPTION
TRACe[:DATA] <char>,<data> command
only
Inputs trace data — choose from
the above list of arrays. The data
can be either BLOCK or NR3
type.
1
Note: See Chapter 6 for
more information.
TRACe[:DATA] <char1>,<char2> command
only
Moves data from one internal
array to another — char1 is the
target array (CH<1|2>SMEM)
while char2 is the source array
(CH<1|2>SDATA). Note that the
source and target arrays must be
from the same measurement
channel.
TRACe:CORRection:SIMulate
[:DATA] {STD1|STD2|...|STD12}
command
only
Reads simulated calibration
standards. Loads pre-computed
or stored measurements of
calibration standards from a
remote controller into the
analyzer.
2
TRACe:CORRection:SIMulate:SAVE
<TRAN1|TRAN2|TRAN3|REFL3|TESTset|
TESTset1|TESTset2|VERIFY||TWOPort
|NONE>
command
only
Computes cal error correction
arrays.
