The Rear Panel at a Glance
The figure below shows the Agilent 3499A rear panel.
The figure below shows the Agilent 3499B rear panel.
Slot 4
Slot 5
Slot 1
Slot 2
Slot 3
GPIB Connector RS-232 Connector
Mini DIN Connector
Power Input
Slot 0
Control Module
Slot 1
Slot 2
GPIB Connector RS-232 Connector
Mini DIN Connector
Power Input
Slot 0
Control Module
