18 Chapter2
Setting Up the EDGE (with GSM) Mode
Changing the Mode Setup
Changing the Mode Setup
Numerous settings can be changed at the mode level by pressing the
Mode Setup key. This will access a menu with the selections listed below.
These settings affect all the measurements in the GSM mode.
Radio
The Radio key accesses a menu to select:
•
Band - Select the GSM band (P-GSM, E-GSM, R-GSM, GSM 450,
GSM 480, GSM 850, DCS 1800, or PCS 1900). Refer to the table in
the previous section for GSM band data.
•
Device - Select the device to test BTS (Base Transceiver Station) or
MS (Mobile Station).
• BTS Type - Select the type of BTS (Base Transceiver Station) to be
tested (Normal, Micro, or Pico).
• Freq Hopping - Turn frequency hopping on or off. If frequency
hopping is turned on, the instrument will ignore the bursts when the
frequency is hopped off the selected channel frequency. Thus only
valid data is included in the results. Only the Power vs. Time, and
the Phase and Frequency Error measurements can be made on
hopping GSM signals.
•
Carrier - Select the type of carrier to measure (Burst or Continuous).
Radio Default Settings
Band E-GSM
Device BTS
BTS Type Normal
Freq Hopping Off
Carrier Burst
