Chapter 2 31
Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
Figure 2-4 Phase and Frequency Error Measurement Key Flow
Phase & Freq
Avg Bursts 10On | Off
Avg Mode Exp | Repeat
Avg Type
Mean
Maximum
Trig Source
Free Run (Immediate)
Video (IF Envlp)
RF Burst (Wideband)
Ext Front
Ext Rear
Frame
Restore Meas Defaults
Measure
Meas Setup
Burst Sync
Training Seq
RF Amptd
Select 1 | 2 | 3 | 4
Normal
Delta
Function
Band Power
Noise
Off
Trace
Phase Error
Phase Error w/Freq
Off
Shape
Diamond
Line
Square
Cross
Marker All Off
Marker
I/Q Measured Polar Vector
View/Trace
Phase & FreqMeasure
I/Q Error (Quad-View)
Phase & FreqMeasure
RF Envelope
Data Bits
