Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
Figure 2-2 Transmit Power Measurement Key Flow
Transmit Pwr
Averages 50 On | Off
Avg Mode Exp | Repeat
Avg Type
Pwr Avg (RMS)
Log-Pwr Avg (Video)
Maximum
Minimum
Trig Source
Free Run (Immediate)
Video (IF Envlp)
RF Burst (Wideband)
Ext Front
Ext Rear
Frame
Restore Meas Defaults
Measure
Meas Setup
Advanced
RBW Filter Gaussian | Flat
Res BW 500.000 kHz
Threshold Lvl -6.00 dB Abs |Rel
Burst Sync None
Meas Time 1 Slot
Select 1 | 2 | 3 | 4
Normal
Delta
Function
Band Power
Noise
Off
Trace
RF Envelope
I/Q Waveform
Off
Shape
Diamond
Line
Square
Cross
Marker All Off
Marker
Transmit PwrMeasure
