Agilent Technologies E4406A VSA Series - Spectrum (Freq Domain) Measurement Key Flow (1 of 3)

Chapter 2 33
Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
Figure 2-6 Spectrum (Freq Domain) Measurement Key Flow (1 of 3)
Spectrum (Freq Domain)
Span 1.00000 MHz
Avg Mode Exp | Repeat
Avg Type
Res BW 20.0000 kHz Auto| Man
Avg Number 25 On | Off
Pwr Avg (RMS)
Log-Pwr Avg (Video)
Voltage Avg
Maximum
Minimum
Trig Source
Free Run (Immediate)
Video (IF Envlp)
RF Burst (Wideband)
Ext Front
Ext Rear
Frame
Line
Restore Meas Defaults
Advanced
Pre-ADC BPF On | Off
Pre-FFT Fltr Gaussian |Flat
Pre-FFT BW 1.55000 MHz Auto| Man
Measure
Meas Setup
FFT Window Flat Top (High Amptd Acc)
Flat Top (High Amptd Acc)
Uniform
Hanning
Hamming
Gaussian (Alpha 3.5)
Blackman
Blackman-Harris
K-B 70 dB (Kaiser-Bessel)
K-B 90 dB (Kaiser-Bessel)
K-B 110 dB (Kaiser-Bessel)
FFT Size
Length Ctrl Auto | Man
Min Pnts/RBW
(a)
Average
