Agilent Technologies E4406A VSA Series Measurement Guide

Chapter 2 39
Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
Figure 2-12 EDGE EVM Measurement Key Flow
EDGE EVM
Avg Bursts 10On | Off
Avg Mode Exp | Repeat
Trig Source
Free Run (Immediate)
Video (IF Envlp)
RF Burst (Wideband)
Ext Front
Ext Rear
Frame
Restore Meas Defaults
Measure
Meas Setup
Burst Sync
Training Seq
RF Amptd
Select 1 | 2 | 3 | 4
Normal
Delta
Function
Band Power
Noise
Off
Trace
MAG Error
Phase Error
Off
Shape
Diamond
Line
Square
Cross
Marker All Off
Marker
Polar Constln
View/Trace
EDGE EVMMeasure
Polar Vector
EDGE EVMMeasure
EVM Error
Droop Comp On | Off
I/Q Error (Quad View)
None
