Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
EDGE (with GSM) Measurement Key Flow
The key flow diagrams, shown in a hierarchical manner on the
following pages, will help the user to grasp the overall functional
relationships for the front-panel keys and the softkeys displayed at the
extreme right side of the screen. The diagrams are:
“Mode Setup / Frequency Channel Key Flow” on page 28
“Transmit Power Measurement Key Flow” on page 29
“Power vs. Time Measurement Key Flow” on page 30
“Phase and Frequency Error Measurement Key Flow” on page 31
“Output RF Spectrum Measurement Key Flow” on page 32
“Spectrum (Freq Domain) Measurement Key Flow (1 of 3)” on
page 33
“Waveform (Time Domain) Measurement Key Flow (1 of 2)” on
page 36
“Tx Band Spur Measurement Key Flow” on page 38
“EDGE EVM Measurement Key Flow” on page 39
“EDGE PvT Measurement Key Flow” on page 40
“EDGE ORFS Measurement Key Flow (1 of 2)” on page 41
Use these flow diagrams as follows:
• There are some basic conventions:
An oval represents one of the front-panel keys.
This box represents one of the softkeys displayed.
This represents an explanatory description on its specific key.
This box represents one of the default condition softkeys displayed.
Default conditions are shown as much as possible with underlined
parameters or values displayed on those softkey labels.
• Follow the measurement diagram from left to right and top to
bottom.
• A single softkey may allow multiple choices. For example; the
Device
softkey reveals two choices, BTS or MS. The underlined choice is the
current state of the instrument. To change choices, press the softkey
one time.
• When entering a numeric value of
Frequency, for example, use the
numeric keypad and terminate the entry with the appropriate unit
selection from the softkeys displayed.
QPSK EVM
View/Trace
<for EVM>
Avg Number 10 On|Off
To Next Page
