Agilent Technologies E4406A VSA Series Measurement Guide

Chapter 3 85
Making EDGE (with GSM) Measurements
Making the Spectrum (Frequency Domain) Measurement
Changing the Measurement Setup
Table 1 Spectrum (Frequency Domain) Measurement Defaults
Measurement Parameter Factory Default Condition
Res BW
Averaging:
Avg Number
Avg Mode
Avg Type
25 On
Exp
Log-Pwr Avg (Video)
Trigger Source
Measurement Time
(Service mode only)
1.0 ms (Auto)
Spectrum Window:
Span
Scale/Div - Amplitude Y Scale 10.00 dB
I/Q Waveform Window:
Capture Time
Scale/Div - Amplitude Y Scale 60 mV
Advanced
Pre-ADC BPF On
Pre-FFT Filter Flat
Pre-FFT BW
FFT Window Flat Top (High AmptdAcc)
FFT Size:
Length Control
Min Points/RBW
Window Length
FFT Length
Auto
1.300000
ADC Range Auto Peak
Data Packing Auto
ADC Dither Auto
Decimation 0 (Auto)
IF Flatness On
