Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
Figure 2-3 Power vs. Time Measurement Key Flow
Pwr vs Time
Avg Bursts 10On | Off
Avg Mode Exp | Repeat
Avg Type
Pwr Avg (RMS)
Log-Pwr Avg (Video)
Maximum
Minimum
Trig Source
Free Run (Immediate)
Video (IF Envlp)
RF Burst (Wideband)
Ext Front
Ext Rear
Frame
Restore Meas Defaults
Measure
Meas Setup
Advanced
RBW Filter Gaussian | Flat
Res BW 508.000 kHz
Meas Time 1 Slot
Burst Sync
Training Seq
RF Amptd
Select 1 | 2 | 3 | 4
Normal
Delta
Function
Band Power
Noise
Off
Trace
RF Envelope
Upper Mask
Off
Shape
Diamond
Line
Square
Cross
Marker All Off
Marker
Rise & Fall
View/Trace
Pwr vs TimeMeasure
Burst
Pwr vs TimeMeasure
Lower Mask
