Agilent Technologies E4406A VSA Series Measurement Guide

Chapter 2 41
Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
Figure 2-14 EDGE ORFS Measurement Key Flow (1 of 2)
EDGE ORFS
Avg Bursts 20 On | Off
Avg Mode Exp | Repeat
Meas Method
Multi-Offset
Single Offset (Examine)
Ofs Freq List
Standard
Short
Custom
Restore Meas Defaults
Measure
Meas Setup
Advanced
Mod Avg
Modulation Meas BWs
Meas Type
Fast Avg On Off
Modulation
Mod & Switch
Switching
Pwr Avg (RMS)
Log-Pwr Avg (Video)
Carrier RBW 30.000 kHz
< 1800 kHz Offset RBW 30.000 kHz
>= 1800 kHz Offset RBW 100.000 kHz
Switching Meas BWs
Carrier RBW 300 kHz
< 1800 kHz Offset RBW 30.000 kHz
>= 1800 kHz Offset RBW 30.000 kHz
Direct Time Break Freq 600.000 kHz
Trig Source
Free Run (Immediate)
RF Burst (Wideband)
Ext Front
Frame
Offset Freq
<Not available in Multi-Offset>
Ext Rear
