Agilent Technologies E4406A VSA Series Measurement Guide

36 Chapter2
Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
Figure 2-9 Waveform (Time Domain) Measurement Key Flow (1 of 2)
Waveform (Time Domain)
Sweep Time
Res BW
Average
Avg Number 10 On | Off
Avg Mode Exp | Repeat
Avg Type
Pwr Avg (RMS)
Log-Pwr Avg (Video)
Maximum
Minimum
Trig Source
Free Run (Immediate)
Video (IF Envlp)
RF Burst (Wideband)
Ext Front
Ext Rear
Frame
Line
Restore Meas Defaults
Measure
Meas Setup
Advanced
Pre-ADC BPF On | Off
RBW Filter Gaussian | Flat
ADC Range
Auto
Auto Peak
AutoPeakLock
Manual
-6 dB
0 dB
+6 dB
+12 dB
+18 dB
+24 dB
