Setting Up the EDGE (with GSM) Mode
EDGE (with GSM) Measurement Key Flow
Figure 2-7 Spectrum (Freq Domain) Measurement Key Flow (2 of 3)
Spectrum
I/Q Waveform
Trace Display
All
Average (or Max & Min)
Current
Spectrum (Freq Domain)Measure
View/Trace
Span
Scale/Div
Ref Value
Span X Scale
Amplitude Y Scale
Ref Position Top | Ctr | Bot
Scale Coupling On | Off
Scale/Div
Ref Value
Span X Scale
Ref Position Left | Ctr | Right
Scale Coupling On | Off
Scale/Div
Ref Value
Amplitude Y Scale
Ref Position Top | Ctr | Bot
Scale Coupling On |Off
ADC Range
Auto
Auto Peak
AutoPeakLock
Manual
-6 dB
0 dB
+6 dB
+12 dB
+18 dB
+24 dB
(a)
Data Packing Auto, Short, Medium, Long
ADC Dither Auto On Off
Decimation 0 Auto Man
IF Flatness On Off
