1-8 Chapter1
Preparing for Use
Turning On the Analyzer for the First Time
Turning On the Analyzer for the First Time
Before using your analyzer, plug the power cord into the analyzer.
Press | (the On key).
Choose a power on preference using the switch on the rear panel (refer
to Figure 2-2 on page 2-8, item 14). The
PWR ALWAYS ON setting turns
the analyzer on whenever external power is applied. This mode is
useful if an external power switch is used to control a rack of several
instruments. The
PWR NORM setting (factory default) assigns analyzer
on/off control to the front-panel On key (see Figure 2-1 on page 2-3,
item 23); however if the external power is removed for > 20 seconds, the
instrument returns to the Standby condition of the front-panel On key
when external power is reconnected.
When you turn on the analyzer, the information screen as shown in
Figure 1-1 will be displayed during initialization of the instrument.
NOTE This screen may be displayed for as long as 1 minute before the
initialization process is complete.
Your analyzer product number, the firmware revision number (A.04.01),
and a URL for accessing product support information on the World
Wide Web are shown.
Figure 1-1 Information Screen Displayed During Initialization
