6-8 Chapter6
Front-Panel Key Reference
AMPLITUDE Y Scale
AMPLITUDE Y Scale
Activates the reference level function and accesses the amplitude menu
keys. Amplitude menu keys allow you to set functions that affect the
way data on the vertical axis is displayed or corrected.
Ref Level Allows the reference level to be changed. This function is activated
when
AMPLITUDE Y Scale is pressed. The reference level is the
amplitude power or voltage represented by the top graticule on the
display. Changing the value of the reference level changes the absolute
amplitude level (in the selected amplitude units) of the top graticule
line. The reference level can be changed using the step keys, the knob,
or the numeric keypad. Pressing any digit (0 through 9) on the numeric
keypad brings up the terminator menu.
Attenuation
Auto Man
Sets the input attenuation in 5 dB increments. The analyzer input
attenuator, which is normally coupled to the reference level control,
reduces the power level of the analyzer input signal at the input mixer.
The attenuator is recoupled when
Attenuation (Auto) is selected.
Attenuation can be changed using the step keys, the knob, or the
numeric keypad.
CAUTION To prevent damage to the input mixer, do not exceed a power level of
+30 dBm at the input. To prevent signal compression, keep the power at
the input mixer below 0 dBm. With the attenuator set to Auto, a signal
at or below the reference level will result in a mixer level at or below
the Max Mixer Lvl.
Scale/Div Sets the logarithmic units per vertical graticule division on the display.
The
Scale/Div function is only available when the Scale Type key is set to
Log. Scale/Div values may range from 0.1 to 20 dB per division (With
Option BAA, the range is 1 kHz to 240 kHz/div when FM Demod View
is enabled.)
Scale Type
Log Lin
Scales the vertical graticule divisions in logarithmic units when Log is
underlined. Logarithmic units may range from 0.1 to 20 dB per
division. When
Lin is underlined, the vertical divisions are linearly
scaled and the default amplitude units are volts. The reference-level
value is set to the top of the display and the bottom graticule becomes
zero volts. (Each division of the graticule is one-tenth of the reference
level in volts.) Pressing
Scale Type Log Lin always sets the units
specified for the current amplitude scale. Pressing
Preset or powering
on the analyzer sets the default units.
To Next Page
