Chapter 6 6-11
Front-Panel Key Reference
AMPLITUDE Y Scale
Point
Allows you to create or edit an amplitude-correction
factor data point. Up to 200 points may be defined for
each set. Enter the point number to be created or edited
by using the numeric keypad, then press
Enter, or use
the knob, Tab, or step keys to move to an existing point.
Press
Bk Sp to correct errors. After selecting a point,
Frequency becomes active. Key Access: AMPLITUDE Y
Scale, More 1 of 2, Corrections, Modify, Edit
Frequency
Allows you to enter the frequency value for an
amplitude-correction point. Enter the frequency value
by using the numeric keypad. Change the frequency
value by using the step keys or the knob. Press
Bk Sp to
correct errors. After selecting a point,
Amplitude
becomes active.
NOTE The amplitude correction entered for the lowest frequency will be
applied to all frequencies less than the lowest frequency entered.
Similarly, the amplitude correction for the highest frequency entered
will be applied to all frequencies greater than the highest frequency
entered.
A frequency coordinate must always be specified for
amplitude-correction factors. Key Access:
AMPLITUDE Y
Scale, More 1 of 2, Corrections, Modify, Edit
NOTE For amplitude-correction factors, a maximum of two entries with the
same frequency are valid. Only the first and last points of a series with
the same frequency values are used; any middle points are ignored.
NOTE Amplitude-correction data is sorted in the table by frequency. The
sorting occurs immediately after you have entered the frequency value
via the front-panel.
Amplitude
Allows you to enter the amplitude value for the current
amplitude-correction point. After selecting a point, the
point number automatically increments and
Frequency
becomes active to allow entry of the frequency of the
next point. Press
Bk Sp to correct errors. Key Access:
AMPLITUDE Y Scale, More 1 of 2, Corrections, Modify, Edit
