6-30 Chapter6
Front-Panel Key Reference
File
When Type is set to Corrections, Source accesses the
Antenna, Cable, Other and User menu keys, which allow
you to select the type of correction to be saved.
When Type is set to Limits, Source accesses the Limit 1
and Limit 2 menu keys. Limit 1 and Limit 2 provide data
sets to determine whether a trace has exceeded preset
specifications. Limit sets can hold up to 200 points and
can only be saved individually.
Name Accesses the Alpha Editor and allows you to enter a
filename. The external keyboard can also be used to
enter a filename while the alpha editor is accessed.
NOTE Only capital letters (A-Z) and digits (0-9) may appear in file names (8
characters, maximum). Additionally, file names include a 3 digit
extension which is automatically set by the instrument.
Dir Up Allows you to move up one directory level. If at the top
level,
Dir Up moves to the drive level, displaying the
available disk drives.
Dir Select Accesses the highlighted directory on your display.
Load Accesses menu keys that allow you to load analyzer setups, states,
traces, limits and corrections into the analyzer from a floppy (A:) drive
or internal flash (C:) drive.
Load Now Executes the load function. When the load is complete,
the message XXXXXX file loaded (where XXXXXX is
the filename) will appear in the status line on your
display.
Type Allows you to select the type of file you want to load.
Setup
Displays all setup files you may wish to load (SET).
Setup files include a complete set of instrument
parameters including traces, states, limits, and
corrections. Loading a setup restores the analyzer (as
closely as possible) to all previous instrument settings
at the time of the save.
State
Displays all state files you may wish to load (STA).
Loading a state restores most settings to the previously
saved values.
