6-106 Chapter6
Front-Panel Key Reference
View/Trace
1↔2 Exchanges the contents of the trace 1 register with the
trace 2 register and puts trace 1 and 2 in view mode.
Key Access:
View/Trace, More 1 of 2, Operations
2 - DL → 2 Subtracts the display line from trace 2 and places the
result in trace 2 and puts trace 2 in view mode. The
2-DL→ 2 function is a math operation. Key Access:
View/Trace, More 1 of 2, Operations
2 ↔ 3 Exchanges the contents of trace 2 with trace 3 and puts
trace 2 and 3 in view mode. Key Access:
View/Trace,
More 1 of 2, Operations
1 → 3 Copies trace 1 into trace 3 and puts trace 3 in view
mode. Key Access:
View/Trace, More 1 of 2, Operations
2 → 3 Copies trace 2 into trace 3 and puts trace 3 in view
mode. Key Access:
View/Trace, More 1 of 2, Operations
Normalize Accesses the following Normalize menu keys: Key Access: View/Trace,
More 1 of 2
Store Ref (1→ 3) Copies trace 1 into trace 3. Store Ref (1→ 3) must be
pressed before pressing
Normalize (On).IfNormalize (On)
is pressed before Store Ref (1→ 3), the error message:
Store reference trace before turning on
Normalize is displayed in the status line, however
Normalize has been activated.
Normalize
On Off Normalize (On) Activates the normalize function. On
each sweep, the normalized trace (Trace 3) is
subtracted from Trace 1 and the result is added to the
normalized reference level. The display shows the
result of the following calculation:
Trace 1 – Normalized Trace + Normalized Reference
Level
The trace data is normalized with respect to the
normalized reference level, even if the value of the
normalized reference level is changed. This function
remains in effect on all subsequent sweeps until it is
turned off.
NOTE Segmented sweep is not available when Normalize (On) is selected.
