2Performance Tests
24 E4416A/E4417A Power Meters Service Guide
8 Connect the E9321A sensor to the power reference.
9 Calibrate the system:
• For the E4416A press
,
• For the E4417A press ,
,
10 Provide a point of reference against which the power meter can base its
measurements:
• Setup: press
, , , ,
,
,
• Entry: read the value shown on the DVM display. Set the reference
voltage on the pop- up window on the power meter to this value and
press . This value provides a point of reference that allows the
power meter and DVM measurements to be compared at varying power
levels.
11 Connect the 30 dB reference attenuator as shown in Figure 2- 3:
Zero
Cal
Cal
Zero
Cal
Cal
Cal A
System
More
Service
Self Test
More
Fast Path Accuracy
Ref Volts at 0.0 dBm
Enter
NOTE
When operating the power meter in this test mode, the range of power levels that can
be applied is +3 dBm to −30 dBm. Power levels outside this range may cause inaccurate
results to be obtained and in some cases may cause damage to the E9321A sensor.
