Performance Tests 2
E4416A/E4417A Power Meters Service Guide 31
It is not necessary to check instrument accuracy in dBm. The power meter
uses the same internal circuitry to measure power and mathematically
converts watts to dBm.
Ta bl e 2 - 3 Instrument Accuracy Results (For Indication Only)
Range Calibrator
Setting
Min
1
Max
1
Channel A Actual
Results
Channel B Actual
Results (E4417A
Only)
3 μW 3.100 μW 3.230 μW _________________ _________________
10 μW 9.900 μW10.10 μW _________________ _________________
30 μW 31.40 μW31.80 μW _________________ _________________
100 μW 99.50 μW100.5 μW _________________ _________________
300 μW314.40 μW 317.60 μW _________________ _________________
1 mW 0.995 mW 1.005 mW _________________ _________________
3 mW 3.141 mW 3.171 mW _________________ _________________
10 mW 9.984 mW 10.08 mW _________________ _________________
30 mW 31.63 mW 31.94 mW _________________ _________________
100 mW 100.9 mW 101.8 mW _________________ _________________
1. These performance limits are determined by the zero set specification of the power sensor used in the measurement plus
the measurement noise.
The nominal outputs for the 3 μW, 30 μW, 300 μW, 3 mW, 10 mW, 30 mW and 100 mW
settings are 3.16 μW, 31.6 μW, 100 μW, 316 μW, 3.156 mW, 10.034 mW, 31.785 mW,
and 101.35 mW respectively.
