Agilent 1260 Infinity VWD User Manual 183
Hardware Information
12
Setting the 8-bit Configuration Switch (without On-board) LAN
Communication Settings for RS-232C
The communication protocol used in the column compartment supports
only hardware handshake (CTS/RTR).
Switches 1 in down and 2 in up position define that the RS- 232C
parameters will be changed. Once the change has been completed, the
column instrument must be powered up again in order to store the values
in the non- volatile memory.
Use the following tables for selecting the setting which you want to use for
RS- 232C communication. The number 0 means that the switch is down
and 1 means that the switch is up.
The following tables represent the configuration switch settings for the modules without
on-board LAN only.
Tabl e 20 8-bit Configuration Switch (without on-board LAN)
Mode Select12345678
RS-232C 0 1 Baudrate Data
Bits
Parity
Reserved 1 0 Reserved
TEST/BOOT 1 1 RSVD SYS RSVD RSVD FC
The LAN settings are done on the LAN Interface Card G1369B/C. Refer to the
documentation provided with the card.
Tabl e 21 Communication Settings for RS-232C Communication (without on-board LAN)
Mode
Select
12345 6 78
RS-232C 0 1 Baudrate Data Bits Parity
To Next Page
