Agilent Technologies G7104C User Manual

1Introduction
Positions of the Multi Purpose Valve
1260 Infinity II Flexible Pump User Manual 18
Normal Operating Mode With Jet Weaver and Optional Inline Filter
In this mode, the flow passes an optional Jet Weaver and the optional inline filter.
This configuration is recommended for special applications which require an
increased mixing efficiency.
Figure 6 Valve position in normal operating mode with Jet Weaver
From pump
To system
Inline filter
Jet Weaver
