Agilent Technologies G7104C User Manual

1260 Infinity II Flexible Pump User Manual 19
1Introduction
Positions of the Multi Purpose Valve
Filter Flush Mode
This mode is used for cleaning the inline filter by back-flushing it. The flow goes
to port 5, passes the inline filter in opposite direction and leaves to the waste
through port 7.
Figure 7 Valve position in filter flush mode
From pump
Inline filter
To waste
CAUTION
Damage to the valve
 Use the filter flush mode only if the optional inline filter is installed.
