24 Agilent Intuvo 9000 GC Installation
1 Installing the GC
Install the stop bracket on the right side of the GC
1 Install the stop bracket with four screws (0515-2113). The
label “ONE DEGREE TILT” should face outward.
2 Install the right-side cover.
“ONE DEGREE TILT”
