Maintenance 5
Agilent U1251B/U1252B User’s and Service Guide 113
Figure 5-8 Fuse replacement
Tab l e 5-4 Fuse specifications
Fuse Agilent part number Rating Size Ty pe
1 2110-1400 440mA/1000V 10 mm x 35 mm
Fast blow Fuse
2 2110-1402 11A/1000V 10 mm x 38 mm
Fuse 1
Fuse 2
