Agilent Technologies U1252B User Manual

Performance Tests and Calibration 6
Agilent U1251B/U1252B User’s and Service Guide 140
Valid adjustment input values
Adjustment can be accomplished using the following input
values below.
Tab l e 6-3 Valid adjustment input values
Function Range Valid Amplitude Input Values
5 V, 50 V, 500 V, 1000 V
0.9 to 1.1 x Full Scale
(for U1251B)
5 V, 50 V, 500 V, 1000 V
0.9 to 1.1 x Full Scale
(for U1252B)
5 V, 50 V ,500 V, 1000 V
0.9 to 1.1 x Full Scale
50 mV, 500 mV, 1000 mV
0.9 to 1.1 x Full Scale
500 µA, 5000 µA
0.9 to 1.1 x Full Scale
50 mA, 440 mA, 5 A, 10 A
0.9 to 1.1 x Full Scale
Ω
500 Ω, 5kΩ, 50 kΩ ,500 kΩ, 5MΩ, 50 MΩ
0.9 to 1.1 x Full Scale
Diode
0.9 to 1.1 x Full Scale
/
10 nF, 100 nF, 1000 nF, 10 µF, 100 µF, 1000 µF,
10 mF / 0 °C
Make sure to provide 0 °C with
ambient compensation
