68 Agilent U1251B/U1252B User’s and Service Guide
3 Features and Functions
Figure 3-11 Frequency adjustment for square wave output
5 Press
to select the pulse width (ms) on the
primary display.
6 Press or to adjust the pulse width. The pulse width
can be set for 256 steps and each step is 1/ (256 x
Frequency). The display range automatically adjusts in the
range of 9.9999~9999.9 ms.
Press
Press
Press
Press
Set Hz
