Getting Started Tutorial 1
Agilent U1251B/U1252B User’s and Service Guide 17
Selecting display with the Dual button
Press to select different combinations of dual
display.Normal single display resumes after you press and
hold for more than 1 second. See Table 1- 8 below.
(DC current)
Frequency (Hz)
DC µAPulse width (ms)
Duty cycle (%)
(AC + DC current)
[for U1252B]
Frequency (Hz)
AC + DC µAPulse width (ms)
Duty cycle (%)
(AC current)
Frequency (Hz)
AC mA or A Pulse width (ms)
Duty cycle (%)
(DC current)
Frequency (Hz)
DC mA or A Pulse width (ms)
Duty cycle (%)
(AC + DC current)
[for U1252B]
Frequency (Hz)
AC + DC mA or APulse width (ms)
Duty cycle (%)
Hz (Frequency counter) - press
to select frequency
division by 1 [for U1252B]
Frequency (Hz)
- 1 -Pulse width (ms)
Duty cycle (%)
Hz (Frequency counter) - press
to select frequency
division by 100 [for U1252B]
Frequency (Hz) - 100 -
